High Precise Positioning Accuracy Linear Motor System
Features:
Higher operating precision
Higher payload slider and smoother operation
High accuracy and operating stability
Clean and durable aluminum alloy materials
Advantages:
1. Zero cogging force to enhance low-speed stability and setting of positioning.
2. Built-in aluminum mounting plate for excellent heat dissipation.
3. Fully covered by metal shielding.
4. Ironless linear motor could be replaced for smaller size and better heat dissipation.
Brand:
HAN'S MOTOROrder(MOQ):
1Products Name: High Precision Good Performance Linear Motion Stage LMD Custom Series
Product Specifications
Parameter
|
Product code |
Stroke range |
Load (Kg) |
Velocity (m/s) |
Acceleration (g) |
Straightness (μm) |
Verticality (μm) |
Repeat accuracy(μm) |
|
X-axis (crossbeam axis) |
100-1000 |
25 |
0.5 |
0.5 |
6/400 |
5/400 |
±1.5 |
|
Y1-axis (Lower axis) |
100-1000 |
/ |
0.5 |
0.5 |
6/400 |
5/400 |
±1.5 |
|
Y2-axis (Lower axis) |
100-1000 |
/ |
0.5 |
0.5 |
6/400 |
5/400 |
±1.5 |
1. Adopt Han's brand U-type linear motor and ACS high-performance control system;
2. The base and beam are made of marble, double-drive gantry structure, strong load capacity and good stability;
3. Adopt high-precision optical ruler feedback system and ultra-high-precision linear guide;
4. It is suitable for high-end inspection equipment, welding and micro-cutting production;
5. It can be choose different types of linear motor models according to requirements, and the Z axis can be expanded;
Characteristics:
1. High stability
High quality materials to ensure the stable operation.
2. High precision
Applied high precision motor to remain a great position repeatability.
3. High load
Anodized aluminum base and parts, to be high rigidity to carry higher load.
4. Easy installation
Why choose us?
Q: What about your company's situation?
A: Established in 2005, it is a subsidiaries of Han’s Laser (Stock Code: 002008), which is one of the global leaders which manufacture professional laser equipment. We are awarded for National High and New Tech Enterprise and National “SRDI” Enterprise.
Q: What's your main products?
A: Specialized in direct drive system in the domestic R&D, promotion, application.Including linear motor、Torque motor 、Motion stage 、AC servo system 、 Variable-Frequency Drive etc. And linear motor market share reached leading level in China.
Passed ISO 9001 and ISO 14001 management system certification and CE certificate.
Aftersales Service:
Applications:
Applicable in automatic product lines, medical equipment, laser cutting equipment, spray machine equipment, dispenser, 3D printing machine etc.
HAN'S Motor Motion Stages Products Series:
Packaging & Delivery:
Packaging Details.: plywood packing
Port.: Shenzhen ( Sea / Air shipping, TNT, UPS, FedEx and DHL ect.)
Leading time: According to the order quantity, 10 days for the small order and 20 days for the bulk order
